Magnum Shock Absorber

Monroe
65109
$158.00 CAD
$158.00

Magnum Shock Absorber
Magnum Front Suspension Shock Absorber
Monroe Magnum 65109 Front Suspension Shock Absorber
BUILT TO LAST -- Robust hydraulic lock-out prevents over extension of air bags, top-out of the piston and averts damage to seal assembly (most applications)
BUY WITH CONFIDENCE -- Comes with Monroe’s 90-day Risk Free Ride Offer and Limited Commercial Warranty
STRONG AND DURABLE -- Shouldered bushing and bonded bushing with sleeve protects from bushing walkout for improved quality; arc welds up to 360° for durability
EXCEPTIONAL HANDLING -- 10-Stage valving, tuned specifically to each vehicle, adjusts to road extremes while the larger 1-3/4-in. bore provides more efficient damping control to provide consistency and a smooth ride (most applications)
FOR HARDWORKING COMMERCIAL VEHICLES -- Designed to handle the demands of high mileage and severe use class 6-8 trucks and buses
IMPROVES PERFORMANCE -- Nitrogen gas-charge maintains tire-to-road contact for improved ride and handling by reducing aeration and shock fade
LONGER SERVICE LIFE -- Bearing with PTFE coating reduces friction between rod and rod guide combined with nitrocarburized piston rod provides durability and longer service life (most applications)
CONSISTENT RIDE -- All-weather fluid contains special additives to assist with extreme temperatures and help reduce oil breakdown while larger 2-3/8-in. reserve tube holds more fluid to improve performance (most applications)
REDUCED NOISE, VIBRATION AND HARSHNESS -- Delivers exceptional control and isolates impact-related noise, vibration and harshness under most driving conditions
The Monroe® Magnum® shock absorber for class 6-8 vehicles is the first gas-charged, large-bore shock for air spring and taper leaf suspensions. The nitrogen gas charge provides the fast response essential for today’s heavy truck suspension systems.
Read More
Read Less
Adjustable Damping
No
Dust Shield Included
Yes
Includes Bump Stop
No
Compressed Length
14
Shock Absorber Rod End Measuring Point
Center of Loop
Shock Absorber Body End Measuring Point
Center of Loop
Finish
Painted
Lower Mount Type
Loop Bushing and Sleeve Mount - 3/4\ Sleeve ID X 1.3/4\ Sleeve OAL
Parts Pack(s)
None
Shaft Diameter
18
Upper Mount Type
Loop Bushing and Sleeve Mount - 3/4\ Sleeve ID X 1.3/4\ Sleeve OAL
Internal Rebound Bumper
No
Dust Shield Material
Metal
Travel Length
8.5
Travel Length
215.9
Internal Construction Type
Twin Tube
Gas Charged
Yes
Compressed Length
355.6
Extended Length
22.5
Color
Black
Foam Cell Design
No
Part Description
Shock Absorber
Upper Mount Code
LS54
Lower Mount Code
LS54
Shock Absorber Bore Size
1.75
Shock Absorber Bore Size
44.5
Extended Length
571.5
Hydraulic Lockout
No
Customer satisfaction is our number 1 priority. If there is any questions that the FAQ cannot answer please contact us via Live Chat, 1-866-461-2787 or Email Us Here always guarantee the fitment of all our auto parts, tires & wheels. Our catalog is maintained daily to ensure you get the right auto parts, tires and wheels the first time!

Please review the available inventory for a basic idea of when the order will ship. The order cutoff for same-day shipping is 12 Noon. Any orders placed after will ship the next day.

Shipping is mostly free. However, in some rare circumstances, we reserve the right to charge additional freight or cancel the order. This is due to rural areas and/or oversized products

Review the complete freight policy by clicking here

Many times we can still source products. However, it may come with extra freight or fees. Simply contact us via live chat or our Contact Us page here.


Our team will be happy to help!

Our team is very accurate in our picking process. We follow multiple verifications to ensure the right part that was ordered is shipped.

Yes, we do. We have a year, make and model verification. Now with the application, there are sometimes some important notes to read about fitments. For 100% confirmation contact us

Absolutely! You can pick up your Auto Parts, Tires, and Wheels at our Ottawa Location. In order to do that please select the pickup in-store option at the checkout. Our team will reach out to you when your parts are ready for pickup. Normally a day turnaround on all available products.

If you want a more precise pickup time, We are easily reached by Live Chat, 1-866-461-2787 or by Email

Our default price is in Canadian dollars

All of our orders can be canceled prior to shipping. Special orders cannot be canceled once we have confirmed the lead times with our clients. All tire and wheel packages cannot be canceled once mounted & balanced. We do ship out pretty quickly. In order to cancel your order please contact us immediately to cancel. The easiest way is to reply to your order confirmation.

Return freight will be charged for the return

Special order items might be refused for return

Warranties vary by manufacturer. Please contact us for confirmation of warranty on parts

Brand Label Part Number
Sachs 315420
Neway 57365109
Mack 650109
Gabriel 654953
Gabriel 85058
Bulldog HD HD12150114
Volvo GM Heavy Truck 20849243
Volvo GM Heavy Truck 3919939
Hendrickson 59992001
Hendrickson 599921
Alliance Truck Parts ABPN32G900073
Meritor M85058
Navistar 1667520C1
Dayton Parts 441850585109
Automann A85058
Alliance Truck Parts ABPN32O900073
Haldex SA65109
Freightliner 1619138000
Navistar 1667520C2
Monroe Shocks & Struts 650109
NAPA Shocks 65109
FCS F347198
